Woburn Ultimate Plus Size Profiling Bed - Bariatric, Aluminium Side Rails, Adjustable Height, 60 Stone Capacity.

The NCL-HLB798 Woburn Ultimate Plus Size Profiling Bed is the ultimate solution for bariatric patients, combining durability, comfort, and functionality. Designed to support patients up to 60 Stone (381 kg), this bed ensures maximum safety and comfort for plus-sized individuals. With aluminium side rails and an under-bed strengthening bar, the Woburn Ultimate is built to handle the demands of bariatric care.

The Woburn Ultimate Plus Size Profiling Bed is engineered for bariatric patients, offering unmatched support and durability. Designed with aluminium side rails and an under-bed strengthening bar, the bed is capable of supporting a maximum weight of 60 Stone (381 kg). It is available in both 1200mm and 1400mm wide options, with an optional 200mm extension for taller patients.

The Woburn Ultimate bed comes equipped with a range of optional bed accessories, such as the Underbed Light, Guardian Wireless Alarm System, Side Rail Bumpers, and Ultimate Lifting Pole. Additionally, a variety of wide-fit, plus-size active and static mattresses are compatible with the bed.

To ensure the end user complies with Bed Rail Regulations, the bed supports a maximum mattress depth of 260mm. The side rails are designed with a two-handed operation for increased safety, preventing accidental releases.

NCL-HLB798.12

Woburn Ultimate Plus Size Profiling Bed - Bariatric, Aluminium Side Rails, Adjustable Height, 60 Stone Capacity.

The NCL-HLB798 Woburn Ultimate Plus Size Profiling Bed is the ultimate solution for bariatric patients, combining durability, comfort, and functionality. Designed to support patients up to 60 Stone (381 kg), this bed ensures maximum safety and comfort for plus-sized individuals. With aluminium side rails and an under-bed strengthening bar, the Woburn Ultimate is built to handle the demands of bariatric care.

The Woburn Ultimate Plus Size Profiling Bed is engineered for bariatric patients, offering unmatched support and durability. Designed with aluminium side rails and an under-bed strengthening bar, the bed is capable of supporting a maximum weight of 60 Stone (381 kg). It is available in both 1200mm and 1400mm wide options, with an optional 200mm extension for taller patients.

The Woburn Ultimate bed comes equipped with a range of optional bed accessories, such as the Underbed Light, Guardian Wireless Alarm System, Side Rail Bumpers, and Ultimate Lifting Pole. Additionally, a variety of wide-fit, plus-size active and static mattresses are compatible with the bed.

To ensure the end user complies with Bed Rail Regulations, the bed supports a maximum mattress depth of 260mm. The side rails are designed with a two-handed operation for increased safety, preventing accidental releases.

Key Features and Benefits:

  • Safe Working Load: 381 kg / 60 Stone
  • Maximum User Weight: 317 kg / 50 Stone
  • Adjustable Height: 275 - 690mm for easy patient access
  • Aluminium side rails for enhanced durability and safety
  • Lockable handset for secure operation
  • Electric backrest and knee break with mechanical lower leg support
  • Trendelenburg position as standard for optimal patient comfort
  • Built-in emergency battery backup for peace of mind
  • Built-in autoregression for easier patient positioning
  • Easy-to-clean design complies with MHRA guidelines
  • Braked wheel castors for additional stability and easy mobility
  • Product Code: NCL-HLB798
  • 5-year warranty

Bed Variations:



NCL-HLB798.12: Dimensions (1200mm Width): 2195mm (L) x 1340mm (W) x 275-690mm (H)

Total Bed Weight (1200mm Width): 157kg (+17kg Side Rails)

Mattress Platform Dimensions: 2000 x 1200mm (1200mm Width)



NCL-HLB798.14: Dimensions (1400mm Width): 2195mm (L) x 1540mm (W) x 275-690mm (H)

Total Bed Weight (1400mm Width): 188kg (+17kg Side Rails)

Mattress Platform Dimensions: 2000 x 1400mm (1400mm Width)



Specifications:

Angle of Back Rest: 70°

Angle of Thigh Rest: 30°

Motor Unit Protection Class: IPX4

Side Rails for Ultimate Bed: Set of 6 (1200mm Width) / Set of 4 (1400mm Width)

Mattress Compatibility:

Hampton Extra Active Mattress

Duke Extra 2.0 Plus Size Active Mattress

Partnership Active Mattress

Reflect 2 Static Mattress

The NCL-HLB798 Woburn Ultimate Plus Size Profiling Bed is the perfect solution for bariatric care, providing maximum comfort, durability, and safety. Whether used with an active or static mattress, this bed will ensure 24-hour pressure area care for patients.

Woburn Ultimate Plus Size Profiling Bed Videos

Woburn Ultimate Plus Size Profiling Bed
Woburn Ultimate Plus Size Profiling Bed
Woburn Ultimate Installation
